Adhesive Hydrogel Electrodes

Single-use adhesive/hydrogel surface electrodes minimize risks of cross-contamination. Available with wires attached (Models 1023, 1025, 1026 and 1029) or with alligator clips (bar, ring, or tab electrode options available). You spend less time and money on labor because you don't have to clean them - just dispose of the electrodes after use.



Compare prewired hydrogel electrodes

The following models include attached leads with standard 1.5 mm touch-proof safety sockets. Compare the Ag/AgCl recording surface, lead length and packaging to select the required configuration.



Model Recording surface Attached lead length Package configuration
1023 12 mm square 24 inches 10 sets of 3 electrodes; 30 total
1025 12 mm square 24 inches 10 sets of 4 electrodes; 40 total
1026 20 mm round 40 inches 10 sets of 4 electrodes; 40 total
1029 40 × 50 mm rectangular 40 inches 20 individually packaged electrodes


What is the difference between 1023 and 1025?

Both have 12 mm square recording surfaces and 24-inch leads. The difference is the set configuration: 1023 contains three electrodes per set—black, red and green—while 1025 contains four, adding a white lead.



Do all hydrogel electrodes include leads?

The four models above are prewired. Other hydrogel electrodes in this collection use separate clip or snap connections. Check the selected product’s connection requirements before ordering.



Find alligator-clip leads and lead-wire extensions for the corresponding setups.
